Remove the Headliner Console

• Gently pull down on the headliner console to release the pressure clips.
• Use a plastic panel removal tool to avoid damage during removal.

Disconnect Console Wiring

• Unplug the wiring harness connector from the console.

Remove Foam Insert

• Locate the factory microphone port and remove the foam insert.

Install the Microphone into the Mount

• Push the rounded end of the microphone through the opening of the mount.
• Make sure the rounded end sits close to the bottom of the center mount support.


Mount the Assembly into the Console

• Insert the mount into the headliner console with the legs and rounded end of the microphone facing down.
• Press until the clip locks securely into place.

Route the Microphone Wire

• Route the wire from the headliner console toward the rearview mirror.
• Reinstall the console, pulling any slack toward the mirror.
• Continue routing the wire across the top of the windshield, down the driver’s side A-pillar, and toward the floorboard.
• Run the wire under the dash and plug the 3.5mm jack into the red microphone port on the back of your Alpine head unit.

Test the System

• Power on the head unit and test the microphone to ensure it is working properly.
